Satel

ASD-200

Wireless smoke and heat detector

$109.01 NZD

Sale Sold out

Product Dimension: ø108 x 61 mm

ASD-200 | Wireless smoke and heat detector

The ASD-200 is a two-way wireless fire detector for ABAX 2/ABAX systems, featuring AES-encrypted communication in ABAX 2.

Dual Detection: Combines a sensitive photoelectric smoke sensor (with unique Swirl chamber and Hexamesh filter) and an integrated thermal sensor.
Alerts & Maintenance: Provides acoustic and optical alarms, plus an LED for chamber soiling, indicating maintenance is needed.
Power Efficient: Runs on a CR123A battery with low consumption. An "ECO" option (ABAX 2) extends battery life up to four times.
Compatibility: Works with various ABAX 2 (up to 2000m range) and ABAX (up to 500m range) controllers and repeaters.
Remote Features: Supports remote firmware updates and includes tamper protection.

Technical Data

Standby current consumption	30 µA
Low battery notification voltage	2,75 V
Static response temperature	54°C
Temperature measurement range	0°C...+55°C
Radio communication range (in open area) for ACU-280	up to 1200 m
Radio communication range (in open area) for ACU-220	up to 2000 m
Radio communication range (in open area) for ACU-270	up to 500 m
Radio communication range (in open area) for ACU-120	up to 500 m
Temperature measurement accuracy	±1°C
Battery working time (in years)	up to 2
Battery	CR123A 3V
Operating frequency band	868,0 ÷ 868,6 MHz
Maximum humidity	93±3%
Weight	172 g
Max. current consumption	50 mA
Operating temperature range	0°C...+55°C
Enclosure dimensions	ø108 x 61 mm
