Satel

NAVY

PIR and glass-break detector

$40.11 NZD

Sale Sold out

Product Dimension: 63 x 96 x 49 mm

NAVY | Dual technology PIR and glass-break detector

The NAVY dual-technology detector combines PIR motion detection with acoustic glass-break detection, ideal for protecting rooms with large windows.

Dual Detection: Integrates PIR motion sensing and acoustic glass-break detection.
Precise Alarms: Offers independent alarm outputs for both motion and glass-break, allowing the control panel to identify the exact source.
Advanced Features: Utilises a new generation digital detection algorithm and ambient temperature compensation for reliable performance.
Customisation: Provides independent sensitivity adjustment for both PIR and glass-break detection.
Pet Immunity: Includes an option for pet immunity, accommodating animals up to 15 kg.

Technical Data

Supply voltage	12 V DC
Detected target velocity	0,3...3 m/s
Operating temperature range	-10...+55 °C
Recommended mounting height	2,4 m
Standby mode current consumption	7,5 mA
Max. current consumption	10 mA
Weight	100 g
Relay contacts rated load (resistive)	40 mA / 16 V DC
Maximum humidity	93±3%
Dimensions	63 x 96 x 49 mm
Environmental class according to EN50130-5	II
Alarm signalling time	2 s
Warm-up period	30 s
Glassbreak detection range	up to 6 m
